DaliControl gc16

Key Features

• Single-Channel DALI Control: Controls up to 64 DALI devices within one channel, ideal for small to medium-sized KNX-based lighting installations.

• Full DALI DT8 Support: Compatible with DALI Device Type 8 (IEC 62386-209) for dynamic colour control including tunable white and RGB/RGBW functionality.

• Flexible Addressing Options: Allows individual, group (up to 16), or broadcast control for versatile and scalable lighting management.

• KNX Integration: Provides seamless communication between DALI and KNX systems for centralised configuration, monitoring, and control via ETS.

• Emergency Lighting Compliance: Supports EN 62386-202 standard for emergency lighting testing and feedback directly over the KNX bus.

• Compact and Reliable Design: 4TE DIN-rail housing ensures easy installation, long-term durability, and efficient use of space within control panels.

Product Description

The IPAS KNX 4101-145-11 DALIcontrol e64 is a single-channel KNX-to-DALI gateway designed to simplify and enhance intelligent lighting control within KNX building automation systems. It enables management of up to 64 DALI luminaires through one channel, supporting flexible configurations including individual, group, and broadcast addressing.

With full DALI Device Type 8 (DT8) compatibility, the gateway provides sophisticated colour management—supporting tunable white and RGB/RGBW lighting control for dynamic, human-centric illumination. It also includes functionality for EN 62386-202 emergency lighting, allowing KNX-triggered function and duration tests with real-time feedback.

Compact and robust, the 4TE DIN-rail mounted device ensures seamless integration into existing KNX installations and can be easily configured via ETS software. The IPAS 4101-145-11 is a reliable, professional-grade solution for precise and energy-efficient lighting automation in commercial and architectural environments.
