HF 360-2 DALI-2 INPUT DEVICE RECESSED - OBS

Key Features:

• 360° high-frequency detection: Capable of detecting movement through materials like glass, wood, and stud walls, with a range of up to Ø 12 m, ideal for stairwells, washrooms, and corridors.
• DALI-2 Input Device integration: Fully compatible with DALI-2 systems, allowing for seamless lighting control in conjunction with building automation systems.
• Concealed installation: Designed for in-ceiling installation, providing an unobtrusive and professional solution for indoor commercial spaces.

Product Description:

The Steinel HF 360-2 DALI-2 IPD Presence Detector is equipped with high-frequency sensor technology, providing reliable motion detection even through glass, wood, and stud walls. With a detection range of up to Ø 12 metres, it is ideal for use in spaces like stairwells, washrooms, and corridors. This detector supports concealed ceiling installation, ensuring a sleek and unobtrusive presence in commercial indoor environments.

Integrated with DALI-2 systems, the HF 360-2 IPD communicates sensor data to advanced lighting control systems, enhancing energy efficiency and ensuring optimal lighting management. The detector also supports interconnection via Bluetooth and DALI bus, enabling scalable installation configurations. With robust environmental sensors for light, temperature, and humidity, the device provides accurate data to building automation systems for comprehensive control.

Key Specifications:

• Detection Technology: High-frequency sensor (5.8 GHz) with light, temperature, and humidity sensors
• Detection Range:
  • Radial: Ø 12 m (113 m²)
  • Tangential: Ø 12 m (113 m²)
• Detection Angle: 360°
• Mounting Height: 2.5 to 4.0 m (optimal at 2.8 m)
• Integration: DALI-2 Input Device, Bluetooth interconnection
• Power Supply: DALI bus-powered, 12.5 – 22 V
• Current Consumption:
  • Max: 84 mA (IEC 62386-101)
  • Typical: 21 mA (at 16 V input)
• Twilight Setting: Adjustable from 2 to 2000 lux
• Operating Temperature: -25°C to +50°C
• IP Rating: IP20 for indoor use
• Installation Type: Concealed ceiling installation
• Material: Plastic (RAL 9003 white)
• Additional Features: Sneak-by guard, master/slave interconnection via Bluetooth and DALI bus​
